남경전기 | DF05C CE Approved Products

Frequency controller

◈ Additional improved function

1. Added S2 Mode Counter function (2-step speed and Complete stop)

2. Installed Output Line earth leakage sensing circuit

3. Installed Output Noise Filter

4. Added Automatic Compensator Function of Input variation voltage, Output voltage (ON / OFF possible)

5. Added Output waveform selection function

Full-Wave : DF-5A output pulse shape

Half-wave : Resonance phenomenon improve waveform, Sharply reduced noise,

Show half-wave with or without dot ( . ) beside V mark

6. Distinguishes between Parameter user mode and Engineer mode

7. Change channel operation method (Can save and operate with 4-channels Individual main channel)

Item		Content		Remark
Model Name		DF05C	DF10C
Environmental Specification	Working Temperature	0 ~ 40℃
	Working Humidity	10 ~ 90%
Electrical Specification	Power Voltage	AC100V ~ 240V, 50HZ ~ 60HZ		Automatic
	Load Current eff	5A	10A	Overload
	Internal Temperture	Stop temperature at 70℃ or Over		Overheat
Output Specification	Control Method	Frequency Setting, Voltage Control
	Output Voltage	0.0V ~ 200.0V
	Variable Frequency	40HZ ~ 400HZ
Operation Specification	Operation Method	Operated with S1 control signal
	Time Setting	0.0 ~ 99.9sec
	Inter-Control	Bowl Feeder / Hopper Feeder
	External Control	Speed control with VR and DC 0 ~ 5V
	Contact Output	Relay contact point output (function selection)
Special Specification	Voltage Compensation	Input, Voltage fluctuation and Output Compensation		Automatic
	Constant Amplitude	Installed VS50, Output voltage by Auto compensation		Automatic
	485 Communication	PLC, PC, DFC-RS Communication		Maximum 32
